GEK-106237P MIFII Digital Feeder Relay 2-27
2 PRODUCT DESCRIPTION 2.16 TECHNICAL SPECIFICATIONS
2
2.16.4 POWER SUPPLY
2.16.5 OUTPUTS
2.16.4.1 LOW RANGE
Rated DC Voltage:
Min./Max. DC Voltage:
24 to 48 Vdc
19 / 58 Vdc
2.16.4.2 HIGH RANGE
Rated DC Voltage:
Min./Max. DC Voltage:
Rated AC Voltage:
Min./Max. AV Voltage:
110 to 250 Vdc
88 / 300 Vdc
110 to 230 Vac @ 50 – 60 Hz
88 / 264 Vac @ 50 – 60 Hz
Power Consumption: Max. = 10 W
Proper backup time (date, time and log
memory) without power supply voltage
> 1 week
2.16.5.1 OUTPUT RELAYS
Configuration: 6 Electro-Mechanical Form C
Contact Material: Silver alloy suited for inductive loads
Maximum Operating Voltage: 400 Vac
Single Contact Carry Continuous: 10 A at 250 Vac. general purpose
¾ HP, 124 Vac
1-1/2 HP, 250 Vac
10A, 250 Vac, 0.4 PF,
B300 pilot duty
Make and Carry: 30 A
Breaking: 4000 VA
