GEK-106237P MIFII Digital Feeder Relay 5-3
5 SETTINGS 5.2 MAIN SETTINGS
5
5.2.2 PHASE / GROUND TOC SETTINGS (51P / 51G) (
PHASE / GROUND IOC SETTINGS (50P1 / 50P2 / 50G1/50G2) (
ENERVISTA MII SETUP HMI DEFAULT RANGE STEP
Phase TOC Function PHASE TOC 51P PHASE TOC 51P
51P Permission to Trip Trip Enable 51P Trip Enable 51P No Yes/No NA
51P Pickup Value Pickup 51P Pickup 51P 0.5 In (Phase) 0.1-2.4 In (Ph) 0.01 In (Ph)
51P Curve Type Curve 51P Curve 51P DEFINITE TIME DEFINITE TIME,
USER, MOD
INVERSE, VERY
INVERSE, EXTR
INVERSE, INVERSE
SHORT, INVERSE
LONG
NA
51P Time Dial TD mult 51P TD mult 51P 0.5 0.05 – 2.00
(IEC curves)
0.01
5 0.5 – 20.0
(ANSI curves)
0.01
0.5 0.5 – 10.0
(IAC curves)
0.01
51P Definite Time Delay Def Time 51P Def Time 51P 1.00 s. 0.00 – 600.00 s. 0.01 s.
Ground TOC Function GROUND TOC 51G GROUND TOC 51G
51G Permission to Trip Trip Enable 51G Trip Enable 51G No Yes/No NA
51G Pickup (for 1/5 A
ground)
Pickup 51G Pickup 51G 0.5 In (Ground) 0.10 – 2.40 In (Gnd) 0.01 In
(Gnd)
51G Pickup (for sensitive
ground)
Pickup 51G Pickup 51G 0.005 A 0.005-0.12 A 0.001 A
51G Curve Type Curve 51G Curve 51G DEFINITE TIME DEFINITE TIME,
USER, MOD
INVERSE, VERY
INVERSE, EXTR
INVERSE, INVERSE
SHORT, INVERSE
LONG
NA
51G Time Dial TD Mult 51G TD Mult 51G 0.5 0.05 – 2.00
(IEC curves)
0.01
5 0.5 – 20.0
(ANSI curves)
0.01
0.5 0.5 – 10.0
(IAC curves)
0.01
51G Definite Time Delay Def Time 51G Def Time 51G 1.00 s. 0 –600.00s. 0.01 s.
ENERVISTA MII SETUP HMI DEFAULT RANGE STEP
Phase IOC High Setting 50P1 Function Phase IOC 50P1
50P1 Permission to Trip 50P1 Trip Trip Enable 50P1 No Yes/No NA
50P1 Tap / Pickup 50P1 Pickup Pickup 50P1 1 In (Phase) 0.1 – 30.0 In (Ph) 0.1 In (Ph)
50P1 Time Delay 50P1 Time Delay Delay 50P1 0 s. 0 – 600.00 s. 0.01 s.
Phase IOC Low Setting 50P2 Function Phase IOC 50P2
50P2 Permission to Trip 50P2 Trip Trip Enable 50P2 No Yes/No NA
50P2 Tap / Pickup 50P2 Pickup Pickup 50P2 1 In (Phase) 0.1 – 30.0 In (Ph) 0.1 In (Ph)
50P2 Time Delay 50P2 Time Delay Delay 50P2 0 s. 0 – 600.00 s. 0.01 s.
Ground IOC High Set. 50G1 Function Ground IOC 50G1
50G1 Permission to Trip 50G1 Trip Trip Enable 50G1 No Yes/No NA
50G1 Tap / Pickup (for 1/5 A
ground)
50G1 Pickup Pickup 50G1 1 In (Ground) 0.1 – 30 In (Gnd) 0.1 In (G)
