5.3.5 OSCILLOGRAPHY MASKS
5.3.6 I
2
COUNTER
This option is available only in MIFII models with OPTION 2.
5.3.7 BREAKER FAILURE TO OPEN
This option is available only in MIFII models with OPTION 2
5.3.8 COLD LOAD PICKUP
This option is available only in MIFII models with OPTION 2
COMMENTS ON SETTINGS:
The factory default HMI password to change any setting is 1. See chapter 8 for details.
The ACTIVE GROUP setting, in the Advanced General Settings, selects which of the two settings groups is active at a
given time. Its default value is 1 (GROUP 1).
The procedure to set the Phase and Ground TOC (Time Delayed Overcurrent) functions (51P / 51N) is the same for both
functions: First, the pickup value must be set (PICKUP); Then, using the CURVE TYPE (current versus time tripping
characteristic curve), the type of time delay preferred is selected, either DEFINITE TIME, or any of the three inverse curves;
If the choice is any of the inverse curves (Inverse, Very Inverse or Extremely Inverse), then the relay takes into account the
TIME DIAL setting, to identify which of the curves in the family must be used (there are 195 different curves for each curve
type, depending on the Time Dial Selected); if the curve type selected is DEFINITE TIME, then the Time Dial setting is
ignored and the time delay used is the one specified in DEFINITE TIME setting.
OSCILLOGRAPHY MASK ENERVISTA MII SETUP DEFAULT RANGE STEP
Oscillography masks Oscillography mask
Oscillo by communications Oscillo by communic. NO Y/N NA
Oscillo by digital input Oscillo by Digital Input NO Y/N NA
Oscillo by trip Oscillo by trip NO Y/N NA
Oscillo by pickup Oscillo by pickup NO Y/N NA
ENERVISTA MII SETUP HMI DEFAULT RANGE STEP
Counter I^2 MAX Value
I
2
limit
Maximum Counter
I
2
T MAX
999.000 0.000-999.000 kA2 0.001 kA2
ENERVISTA MII SETUP HMI DEFAULT RANGE STEP
Breaker failure to open Breaker failure to open BF
Breaker failure to open enable Breaker failure function Function NO Y/N NA
Fail to open timer Fail to open timer Delay 400 50-999 ms 1 ms
ENERVISTA MII SETUP HMI DEFAULT RANGE STEP
Cold load pickup Cold load pickup CLP
Cold load pickup enable Cold load pickup function Function NO Yes/No NA
Pickup time T IN Outage Time 2.000 0.000-60.000 s 0.001 s
Drop out time T OUT On Load Time 2.000 0.000-60.000 s 0.001 s
Constant. 50P pickup K 50P Phase IOC Mult 1.00 1.00-5.00 0.01
Constant 51P pickup K 51P Phase TOC Mult 1.00 1.00-5.00 0.01
