GEK-106237P MIFII Digital Feeder Relay 5-5
5 SETTINGS 5.2 MAIN SETTINGS
5
5.2.4 AUTORECLOSER SETTINGS (79)
ENERVISTA MII
SETUP
HMI DEFAULT RANGE STEP
Autorecloser (79) AUTORECLOSER 79 AUTORECLOSE
R 79
Autorecloser Function Autorecloser Function AR Function No Yes / No N/A
Number of shots Number of shots AR Max Shots 1 1 – 4 1
Delay before 1
st
reclosure
AR Dead Time Shot 1 AR Dead Time 1 1 s 0.1 – 600 0.01
Delay before 2
nd
reclosure
AR Dead Time Shot 2 AR Dead Time 2 2 s 0.1 – 600 0.01
Delay before 3
rd
reclosure
AR Dead Time Shot 3 AR Dead Time 3 3 s 0.1 – 600 0.01
Delay before 4
th
reclosure
AR Dead Time Shot 4 AR Dead Time 4 4 s 0.1 – 600 0.01
Time delay to reset from lockout
status
AR Reset Lockout
Time
AR Rst LO Delay 10 s 0.1 – 600 0.01
Time for incomplete sequence AR Incomplete
Sequence Time
AR Inc Seq Time 5 s 0.1 – 600 0.01
Recloser reset time after a
successful reclosure
AR Reset Time AR Reset Time 10 s 0.1 – 600 0.01
AUTORECLOSE INITIATION MASKS
Permission for 50P1 to Init
Autorecloser
AR 50P1 Permission
Init
AR 50P1 Init Yes Yes / No N/A
Permission for 50G1 to Init
Autorecloser
AR 50G1 Permission
Init
AR 50G1 Init Yes Yes / No N/A
Permission for 50P2 to Init
Autorecloser
AR 50P2 Permission
Init
AR 50P2 Init Yes Yes / No N/A
Permission for 50G2 to Init
Autorecloser
AR 50G2 Permission
Init
AR 50G2 Init Yes Yes / No N/A
Permission for 51P to Init
Autorecloser
AR 51P Permission Init AR 51P Init Yes Yes / No N/A
Permission for 51G to Init
Autorecloser
AR 51G Permission Init AR 51G Init Yes Yes / No N/A
Permission for 49 to Init
Autorecloser
AR 49 Permission Init AR 49 Init Yes Yes / No N/A
Permission for a DI to Init
Autorecloser
AR External
Permission Init
AR EXTERN Init Yes Yes / No N/A
AFTER 1
ST
TRIP MASKS
Permission for 50P1 function to
trip after Shot 1
AR 50P1 Shot 1
Permission
AR 50P1 Shot 1 Yes Yes / No N/A
Permission for 50G1 function to
trip after Shot 1
AR 50G1 Shot 1
Permission
AR 50G1 Shot 1 Yes Yes / No N/A
Permission for 50P2 function to
trip after Shot 1
AR 50P2 Shot 1
Permission
AR 50P2 Shot 1 Yes Yes / No N/A
Permission for 50G2 function to
trip after Shot 1
AR 50G2 Shot 1
Permission
AR 50G2 Shot 1 Yes Yes / No N/A
Permission for 51P function to
trip after Shot 1
AR 51P Shot 1
Permission
AR 51P Shot 1 Yes Yes / No N/A
Permission for 51G function to
trip after Shot 1
AR 51G Shot 1
Permission
AR 51G Shot 1 Yes Yes / No N/A
Permission for 49 function to trip
after Shot 1
AR 49 Shot 1
Permission
AR 49 Shot 1 Yes Yes / No N/A
