5-6 MIFII Digital Feeder Relay GEK-106237P
5.2 MAIN SETTINGS 5 SETTINGS
5
ENERVISTA MII
SETUP
HMI DEFAULT RANGE STEP
AFTER 2
ND
TRIP MASKS
Permission for 50P1 function to
trip after Shot 2
AR 50P1 Shot 2
Permission
AR 50P1 Shot 2 Yes Yes / No N/A
Permission for 50G1 function to
trip after Shot 2
AR 50G1 Shot 2
Permission
AR 50G1 Shot 2 Yes Yes / No N/A
Permission for 50P2 function to
trip after Shot 2
AR 50P2 Shot 2
Permission
AR 50P2 Shot 2 Yes Yes / No N/A
Permission for 50G2 function to
trip after Shot 2
AR 50G2 Shot 2
Permission
AR 50G2 Shot 2 Yes Yes / No N/A
Permission for 51P function to
trip after Shot 2
AR 51P Shot 2
Permission
AR 51P Shot 2 Yes Yes / No N/A
Permission for 51G function to
trip after Shot 2
AR 51G Shot 2
Permission
AR 51G Shot 2 Yes Yes / No N/A
Permission for 49 function to trip
after Shot 2
AR 49 Shot 2
Permission
AR 49 Shot 2 Yes Yes / No N/A
AFTER 3
RD
TRIP MASKS
Permission for 50P1 function to
trip after Shot 3
AR 50P1 Shot 3
Permission
AR 50P1 Shot 3 Yes Yes / No N/A
Permission for 50G1 function to
trip after Shot 3
AR 50G1 Shot 3
Permission
AR 50G1 Shot 3 Yes Yes / No N/A
Permission for 50P2 function to
trip after Shot 3
AR 50P2 Shot 3
Permission
AR 50P2 Shot 3 Yes Yes / No N/A
Permission for 50G2 function to
trip after Shot 3
AR 50G2 Shot 3
Permission
AR 50G2 Shot 3 Yes Yes / No N/A
Permission for 51P function to
trip after Shot 3
AR 51P Shot 3
Permission
AR 51P Shot 3 Yes Yes / No N/A
Permission for 51G function to
trip after Shot 3
AR 51G Shot 3
Permission
AR 51G Shot 3 Yes Yes / No N/A
Permission for 49 function to trip
after Shot 3
AR 49 Shot 3
Permission
AR 49 Shot 3 Yes Yes / No N/A
AFTER 4
TH
TRIP MASKS
Permission for 50P1 function to
trip after Shot 4
AR 50P1 Shot 4
Permission
AR 50P1 Shot 4 Yes Yes / No N/A
Permission for 50G1 function to
trip after Shot 4
AR 50G1 Shot 4
Permission
AR 50G1 Shot 4 Yes Yes / No N/A
Permission for 50P2 function to
trip after Shot 4
AR 50P2 Shot 4
Permission
AR 50P2 Shot 4 Yes Yes / No N/A
Permission for 50G2 function to
trip after Shot 4
AR 50G2 Shot 4
Permission
AR 50G2 Shot 4 Yes Yes / No N/A
Permission for 51P function to
trip after Shot 4
AR 51P Shot 4
Permission
AR 51P Shot 4 Yes Yes / No N/A
Permission for 51G function to
trip after Shot 4
AR 51G Shot 4
Permission
AR 51G Shot 4 Yes Yes / No N/A
Permission for 49 function to trip
after Shot 4
AR 49 Shot 4
Permission
AR 49 Shot 4 Yes Yes / No N/A
