9-16 MIFII Digital Feeder Relay GEK-106237P
9.15 PHASE TOC ELEMENT (51P) 9 RELAY COMMISSIONING
9
9.15.4 ANSI INVERSE CURVE
Set the relay as follows:
Apply 0.9 times the pickup current into phase A and the relay should not trip.
Apply 1.5 times the pickup current and the relay should trip between 36.2 and 51.3 sec.
Apply 5 times the pickup current and the relay should trip between 3.9 and 4.3 sec.
9.15.5 ANSI VERY INVERSE CURVE
Set the relay as follows:
Apply 0.9 times the pickup current into phase B and the relay should not trip.
Apply 1.5 times the pickup current and the relay should trip between 26.7 and 37.3 sec.
Apply 5 times the pickup current and the relay should trip between 2.4 and 2.8 sec.
9.15.6 ANSI EXTREMELY INVERSE CURVE
Set the relay as follows:
Apply 0.9 times the pickup current into phase C and the relay should not trip.
Apply 1.5 times the pickup current and the relay should trip between 17.2 and 23.6 sec.
Apply 5 times the pickup current and the relay should trip between 1.7 and 1.35 sec.
9.15.7 IAC INVERSE CURVE
Set the relay as follows:
Apply 0.9 times the pickup current at the ground terminals and the relay should not trip.
Apply 1.5 times the pickup current and the relay should trip between 10.86 and 12.25 sec.
Apply 5 times the pickup current and the relay should trip between 3.69 and 4.16 sec.
51P SETTINGS GROUP
Curve INVERSE
Time Dial 10
51P SETTINGS GROUP
Curve VERY INVERSE
Time Dial 10
51P SETTINGS GROUP
Curve EXTREMELY INVERSE
Time Dial 5
51P SETTINGS GROUP
Curve INVERSE
Time Dial 10
