GEK-106237P MIFII Digital Feeder Relay 9-27
9 RELAY COMMISSIONING 9.19 USER SETTINGS
9
ENERVISTA MII SETUP HMI USER
SETTING
RANGE STEP
50G1 Tap / Pickup (for
sensitive ground)
50G1 Pickup Pickup 50G1 0.005-0.12 A 0.001 A
50G1 Time Delay 50G1 Time Delay Delay 50G1 0 – 600.00 s. 0.01 s.
Ground IOC Low Setting 50G2 Function Ground IOC 50G2
50G2 Permission to Trip 50G2 Trip Trip Enable 50G2 Yes/No NA
50G2 Tap / Pickup (for 1/5
A ground)
50G2 Pickup Pickup 50G2 0.1 – 30 In (Gnd) 0.1 In (G)
50G2 Tap / Pickup (for
sensitive ground)
50G2 Pickup Pickup 50G2 0.005-0.12 A 0.001 A
50G2 Time Delay 50G2 Time Delay Delay 50G2 0 – 600.00 s. 0.01 s.
Thermal Image (49) 49 Function THERMAL MODEL 49
Permission to Trip 49 Trip Trip Enable 49 Yes/No NA
49 Tap / Pickup 49 Pickup Pickup 49 0.10 – 2.4 In (Ph) 0.01 In (Ph)
Overload Percent Alarm 49 Alarm Level Alarm Level 49 70% – 100% ITH 1%
Heating Time Constant τ1 T1 Heat Time 49 3 – 600 min. 1 min
Cooling Time Constant τ2 T2 Cool Time 49 1 – 6 times τ11
Autorecloser (79) AUTORECLOSER 79 AUTORECLOSER 79
Autorecloser Function Autorecloser Function AR Function Yes / No N/A
Number of shots Number of shots AR Max Shots 1 – 4 1
Delay before 1
st
reclosure
AR Dead Time Shot 1 AR Dead Time 1 0.1 – 600 0.01
Delay before 2
nd
reclosure
AR Dead Time Shot 2 AR Dead Time 2 0.1 – 600 0.01
Delay before 3
rd
reclosure
AR Dead Time Shot 3 AR Dead Time 3 0.1 – 600 0.01
Delay before 4
th
reclosure
AR Dead Time Shot 4 AR Dead Time 4 0.1 – 600 0.01
Time delay to reset from
lockout status
AR Reset Lockout Time AR Rst LO Delay 0.1 – 600 0.01
Time for incomplete
sequence
AR Incomplete
Sequence Time
AR Inc Seq Time 0.1 – 600 0.01
Recloser reset time after a
successful reclosure
AR Reset Time AR Reset Time 0.1 – 600 0.01
Permission for 50P1 to
Init Autorecloser
AR 50P1 Permission Init AR 50P1 Init Yes / No N/A
Permission for 50G1 to
Init Autorecloser
AR 50G1 Permission Init AR 50G1 Init Yes / No N/A
Permission for 50P2 to
Init Autorecloser
AR 50P2 Permission Init AR 50P2 Init Yes / No N/A
Permission for 50G2 to
Init Autorecloser
AR 50G2 Permission Init AR 50G2 Init Yes / No N/A
Permission for 51P to Init
Autorecloser
AR 51P Permission Init AR 51P Init Yes / No N/A
Permission for 51G to Init
Autorecloser
AR 51G Permission Init AR 51G Init Yes / No N/A
Permission for 49 to Init
Autorecloser
AR 49 Permission Init AR 49 Init Yes / No N/A
Permission for a DI to Init
Autorecloser
AR External Permission
Init
AR EXTERN Init Yes / No N/A
