Inspection and Maintenance — GEK 107048Standard Practices
SP-16
Tool Name FigureQuantityApplication
Tool, Transition Piece
Go/No — Go Gauge
Measure Transition Piece to First-Stage
Nozzle Retaining Ring clearances
1 2-12
Alignment Fixture For Aligning Accessory Gear to Turbine 1 2-13
Fuel Nozzle Staking Tool Stake Lockplate to Fuel Nozzle Body and
Outer Tip
1 2-14
Combustion Liner Puller For Removal of Combustion Liners From
Combustion Casing
1 2-15
Rail Fabrication Hoist For Turbine Casing Removal and Installation 1 2-16
Beam, Lifting For Turbine Casing and Exhaust Frame
Removal and Installation
1 2-17
Sling, Cable For Turbine Casing and Exhaust Frame
Removal and Installation
4 2-18
Hoist, Trolley Used With Hoist Rail Fabrication For Turbine
Casing and Exhaust Frame Removal and
Installation
1 2-19
Shackle, Anchor Used For Turbine Casing and Exhaust Frame
Removal and Installation
11 2-20
Hook, Clevis Foundry Used For Turbine Casing and Exhaust Frame
Removal and Installation
4 2-21
Ratchet, Gear
Come-Along
Used For Turbine Casing and Exhaust Frame
Removal and Installation
2 2-22
Link, Connection Used For Turbine Casing and Exhaust Frame
Removal and Installation
4 2-23
Hook, Clevis Grab Used For Turbine Casing and Exhaust Frame
Removal and Installation
2 2-24
Sling, Chain Used for Turbine Casing and Exhaust Frame
Removal and Installation
2 2-25
Rail Fabrication Hoist For Turbine Casing and Exhaust Frame
Removal and Installation
1 2-26
Pulley For Second and Third-Stage Nozzle Segment
Removal
3 2-27
Borescope Kit Used for Borescope Inspection on Gas
Turbine
1 2-28
Rail Channel Trolley Used in the Accessory Compartment for
Component Lifts
1 2-29
Beam Lifting Inlet Duct Used for Lifting Inlet Silencer 1 2-30
Beam Lifting Inlet Duct Used for Lifting Inlet Transition Piece 1 2-31
Beam Lifting Inlet Duct Used for Lifting Inlet Elbow Section 1 2-32
