Standard PracticesInspection and Maintenance — GEK 107048
SP-55
MS-6001B DLN-1 — Major Inspection Recommended Spare Parts (Cont’d)
Recommended
Quantity
BEARING NO. 2 ASSEMBLY (ML1502) (Cont’d)
2. Deflector, forward Bearing No. 2 1
3. Seal, Stationary Oil, Bearing No. 2 1
4. Pin, Anti-Rotation, Seal 1
5. Pin, Anti-Rotation, Seal 2
6. Locking Plate 4
7. Locking Plate 4
BEARING THRUST, NO. 1 BEARING (ML1507)
1. Shim (Loaded Thrust Bearing) 1
2. Shim (Unloaded Thrust Bearing) 1
3. Bearing Thrust, No. 1 Bearing 1
4. Bearing, Loaded Thrust 1
ROTOR ASSEMBLY, TURBINE (ML1305)
1. First Stage Buckets (Complete Set) 1
2. Pin Shank Seal, First Stage Buckets 92
3. Pin Seal, First Stage Buckets 92
4. Wire Lock, First Stage Buckets 1
5. Pin Shank Seal, Second Stage Buckets 92
6. Pin Platform Seal, Second Stage Buckets 92
7. Wire Lock, Second Stage Buckets 1
8. Pin Dowel, First & Second Stage Buckets (Wire Lock) 12
9. Pin Shank Seal, Third Stage Buckets 92
10. Pin Platform Seal, Third stage Buckets 92
11. Lock Twist, Third Stage Buckets 92
DUCTING AND PLENUM ARRANGEMENT INLET (ML1612, A041)
Note: The list of gaskets, nuts and bolts shown below with varying quantities,
indicates that there are different sizes required. Using the applicable
ducting and plenum arrangement inlet drawings, the user should pro-
cure the gasketing quantities shown and approximately 20% of the
hardware quantities shown to cover any hardware which may not be
reusable.
1. Bolt, Hex Head (Plenum Arrangement) N22P25020 *30*
2. Washer, Plain (Plenum Arrangement) N402P43 *25*
3. Nut (Plenum Arrangement) N235P125 *25*
**4. Gasket, Duct (Plenum Arrangement) 1
To Next Page
