CHAPTER 5: STATUS COMMUNICATIONS
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 5–9
* Launch speed is measured by comparing the time stamp in SOE of digital remote output
status change to the time stamp of message seen on the network by a computer who’s
clock is synchronized by an IRIG-B card to the same IRIG-B source as the 850
relay.
REMOTE INPUTS
Path: Status > Communications > Remote Inputs
The present state of the 32 remote inputs are shown here. The state displayed is the
remote point unless the remote device has been established to be “Offline” in which case
the value shown is the programmed default state for the remote input.
GGIO1 INDICATIONS
Path: Status > Communications > GGIO1 Indications
The present state of the 32 GGIO1 Indications are shown here. There are up to 32 GGIO
indications that can be used to map any FlexLogic operand into the IED 61850 information
model. Default value is Off.
GOOSE STATUS
Path: Status > Communications > GOOSE Status
GOOSE 1 to 64 Status
Range: OFF, ON
Default: OFF
GOOSE HEADER
Path: Status > Communications > GOOSE HDR Status
GOOSE 1 to 64 H.Status
Range: OFF, ON
Default: OFF
GOOSE ANALOG
Path: Status > Communications > GOOSE Analog AV
FLOAT 1 to 24
Range:
Default: 0.0
SINT32 1 to 8
Range:
Default: 0
IEC 61850 STATUS
Path: Status > Communications > IEC 61850 Status
Service Launch
Speed*
Support for
Programmable
time to live
# of Tx # of Rx Test Bit
Support
Number of
items in
each
transmissi
on or
reception
Number of
remote
inputs per
relay
Configurab
le GOOSE
Within 2 ms
(1 CPU
scan)*
Time to live
programmable
from 1000 to
60000 ms
38
Devices
Y64 Data
Items per
Data Set
32
