GE Multilin 850

2–24 850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
ELECTRICAL INSTALLATION CHAPTER 2: INSTALLATION
Table 2-7: Slots F,G,H with I/O options A,A,A (left) and I/O options A, L, A (right)
13 RELAY_5 RELAY_13 RELAY_21 13 Digital In_1 Digital In_8
14 RELAY_5 RELAY_13 RELAY_21 14 Digital In_2 Digital In_9
15 RELAY_5 RELAY_13 RELAY_21 15 Digital In_3 Digital In_10
16 RELAY_6 RELAY_14 RELAY_22 16 Digital In_4 Digital In_11
17 RELAY_6 RELAY_14 RELAY_22 17 Digital In_5 Digital In_12
18 RELAY_6 RELAY_14 RELAY_22 18 Digital In_6 Digital In_13
19 RELAY_7 RELAY_15 RELAY_23 19 Digital In_7 Digital In_14
20 RELAY_7 RELAY_15 RELAY_23 20 Common Common
21 RELAY_7 RELAY_15 RELAY_23 21 +24V +24V
22 RELAY_8 RELAY_16 RELAY_24 22 RELAY_8 RELAY_16
23 RELAY_8 RELAY_16 RELAY_24 23 RELAY_8 RELAY_16
24 RELAY_8 RELAY_16 RELAY_24 24 RELAY_8 RELAY_16
Slots F,G,H with I/O options A,A,A Slots F,G,H with I/O options A,L,A
Terminal # SLOT F SLOT G SLOT H Terminal # SLOT F SLOT G SLOT H
1 RELAY_1 RELAY_9 RELAY_17 1 RELAY_1 Analog Out_1 RELAY_9
2 RELAY_1 RELAY_9 RELAY_17 2 RELAY_1 Analog Out_2 RELAY_9
3 RELAY_1 RELAY_9 RELAY_17 3 RELAY_1 Analog Out_3 RELAY_9
4 RELAY_2 RELAY_10 RELAY_18 4 RELAY_2 Analog Out_4 RELAY_10
5 RELAY_2 RELAY_10 RELAY_18 5 RELAY_2 Analog Out_5 RELAY_10
6 RELAY_2 RELAY_10 RELAY_18 6 RELAY_2 Analog Out_6 RELAY_10
7 RELAY_3 RELAY_11 RELAY_19 7 RELAY_3 Analog Out_7 RELAY_11
8 RELAY_3 RELAY_11 RELAY_19 8 RELAY_3 Return RELAY_11
9 RELAY_3 RELAY_11 RELAY_19 9 RELAY_3 Shield RELAY_11
10 RELAY_4 RELAY_12 RELAY_20 10 RELAY_4 Analog In_1 RELAY_12
11 RELAY_4 RELAY_12 RELAY_20 11 RELAY_4 Analog In_2 RELAY_12
12 RELAY_4 RELAY_12 RELAY_20 12 RELAY_4 Analog In_3 RELAY_12
13 Digital In_1 Digital In_8 Digital In_15 13 Digital In_1 Analog In_4 Digital In_8
14 Digital In_2 Digital In_9 Digital In_16 14 Digital In_2 Return Digital In_9
15 Digital In_3 Digital In_10 Digital In_17 15 Digital In_3 Shield Digital In_10
16 Digital In_4 Digital In_11 Digital In_18 16 Digital In_4 Reserved Digital In_11
17 Digital In_5 Digital In_12 Digital In_19 17 Digital In_5 Reserved Digital In_12
18 Digital In_6 Digital In_13 Digital In_20 18 Digital In_6 Reserved Digital In_13
19 Digital In_7 Digital In_14 Digital In_21 19 Digital In_7 RTD_Hot Digital In_14
20 Common Common Common 20 Common RTD_Comp Common
21 +24V +24V +24V 21 +24V RTD_Return +24V
22 RELAY_8 RELAY_16 RELAY_24 22 RELAY_8 Shield RELAY_16
23 RELAY_8 RELAY_16 RELAY_24 23 RELAY_8 Reserved RELAY_16
24 RELAY_8 RELAY_16 RELAY_24 24 RELAY_8 Reserved RELAY_16
Slots F,G,H Terminal Master Identifier Slots F,G,H with I/O options A,A,N
Terminal # SLOT F SLOT G SLOT H Terminal # SLOT F SLOT G
