GE Multilin 850

CHAPTER 2: INSTALLATION ELECTRICAL INSTALLATION
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 2–25
Table 2-8: Slots F,G,H with I/O options A,A,F (left) and I/O options A, N, F (right)
Slots F,G,H with I/O options A,A,F Slots F,G,H with I/O options A,N,F
Terminal # SLOT F SLOT G SLOT H Terminal # SLOT F SLOT H
1 RELAY_1 RELAY_9 Digital In_15 1 RELAY_1 Digital In_8
2 RELAY_1 RELAY_9 Digital In_16 2 RELAY_1 Digital In_9
3 RELAY_1 RELAY_9 Digital In_17 3 RELAY_1 Digital In_10
4 RELAY_2 RELAY_10 Digital In_18 4 RELAY_2 Digital In_11
5 RELAY_2 RELAY_10 Digital In_19 5 RELAY_2 Digital In_12
6 RELAY_2 RELAY_10 Digital In_20 6 RELAY_2 Digital In_13
7 RELAY_3 RELAY_11 Digital In_21 7 RELAY_3 Digital In_14
8 RELAY_3 RELAY_11 Digital In_22 8 RELAY_3 Digital In_15
9 RELAY_3 RELAY_11 Digital In_23 9 RELAY_3 Digital In_16
10 RELAY_4 RELAY_12 Digital In_24 10 RELAY_4 Digital In_17
11 RELAY_4 RELAY_12 Common 11 RELAY_4 Common
12 RELAY_4 RELAY_12 +24V 12 RELAY_4 +24V
13 Digital In_1 Digital In_8 ARC
FLASHSensor
1Sensor
2Sensor
3Sensor 4
ARC
FLASHSensor
1Sensor
2Sensor
3Sensor 4
14 Digital In_2 Digital In_9 14 Digital In_2
15 Digital In_3 Digital In_10 15 Digital In_3
16 Digital In_4 Digital In_11 16 Digital In_4
17 Digital In_5 Digital In_12 17 Digital In_5
18 Digital In_6 Digital In_13 18 Digital In_6
19 Digital In_7 Digital In_14 19 Digital In_7
20 Common Common 20 Common
21 +24V +24V 21 +24V
22 RELAY_8 RELAY_16 22 RELAY_8
23 RELAY_8 RELAY_16 23 RELAY_8
24 RELAY_8 RELAY_16 24 RELAY_8
