GEK-113032A W650 Wind Generator Protection System 1-3
1 GETTING STARTED 1.1 IMPORTANT PROCEDURES
1
1.1.1.2 MAGNETIC MODULE TERMINALS
The transformer module for the VTs and CTs is already connected to a female connector screwed to the case. The
current inputs incorporate shorting bars, so that the module can be extracted without the need to short-circuit the
currents externally. It is very important, for safety reasons not to change or switch the terminals for CTs and VTs.
Figure 1–3: REAR VIEW OF W650 UNIT
GE Multilin
will not be responsible for any damage of the relay, connected equipment or personnel
whenever these safety rules are not followed.
