2 PRODUCT DESCRIPTION 2.3 ORDERING CODE
2
2.3ORDERING CODE
W650 units are supplied as ½ 19” rack, 6 units high, containing the following modules: power supply, CPU, I/O modules,
communication modules. The required information to completely define an W650 model is shown on Table 2–1:
Table 2–1: ORDERING CODE
Notes:
(1) The digit selected for option G must be equal or higher than the digit selected for option F:
W650***F1G5*****: is a valid selection W650***F5G1*****: is an invalid selection
As exceptions to this rule, 0 is always available for option G, and F2G1 is also a valid selection.
W650 - - - F - G - - - - - DESCRIPTION
B Basic display (4x20 characters)
M Graphic display (240x128 pixels)
REAR SERIAL COMMUNICATIONS BOARD 1
F None
A Redundant RS485
P Redundant plastic fiber optic
G Redundant glass fiber optic
X Redundant RS485 + fiber Can port (CANopen)
Y Redundant plastic fiber optic + fiber Can port (CANopen)
Z Redundant glass fiber optic + fiber Can port (CANopen)
C CableCan port (CANopen)
M Cable can port (CANopen)+RS485
REAR ETHERNET COMMUNICATIONS BOARD 2
B 10/100 Base TX
C 10/100 Base TX + 100 Base FX
D 10/100 Base TX + Redundant 100 Base FX
E Redundant 10/100 Base TX
I/O BOARD IN SLOT F
1 16 Digital Inputs + 8 Outputs
2 8 Digital Inputs + 8 Outputs + 2 trip/close circuit supervision
circuits
4 32 Digital Inputs
5 16 Digital Inputs + 8 Analog Inputs
I/O BOARD IN SLOT G
0 None
1 16 Digital Inputs + 8 Outputs
4 32 Digital Inputs (see Note 1)
5 16 Digital Inputs + 8 Analog Inputs (See Note 1)
AUXILIARY VOLTAGE
LO 24-48 Vdc (range 19.2 – 57.6)
HI 110-250 Vdc (range 88 – 300)
120-230 Vac (range 96 – 250)
LOR Redundant LO
HIR Redundant HI
COMMUNICATION PROTOCOL
- Without IEC 61850 protocol
6 IEC 61850
ENVIRONMENTAL PROTECTION
- Without Harsh (Chemical) Environment Conformal Coating
H Harsh (Chemical) Environment Conformal Coating
