GE Multilin W650 - C.5.3 Multiple Dnp 3.0 Masters Communication with W650

GEK-113032A W650 Wind Generator Protection System C-15
APPENDIX C C.5 DNP CONFIGURATION EXAMPLES
C
C.5.3 MULTIPLE DNP 3.0 MASTERS COMMUNICATION WITH W650
Typical architecture of multi-master communication using DNP 3.0.
Figure C–1: MULTIPLE DNP3.0 MASTERS COMMUNICATING WITH W650
Hub or
Switch
DNP3 Master 2
Scada Device
DNP3 Slave
F650 Relay
DNP3 over TCP/IP
DNP3 Master 3
RTU Device
DNP3 Master 1
Scada Device
