GE Multilin W650 - Switchgear

5-24 W650 Wind Generator Protection System GEK-113032A
5.3 SYSTEM SETUP 5 SETTINGS
5
5.3.4 SWITCHGEAR
In firmware release 1.70 and higher ones there is the possibility to enable or disable the generation of internal signals for
the different elements (protection, control, inputs and outputs, switchgear) available in the device.
The configuration of snapshot events for each switchgear (enable or disable) can be selected at Setpoint > System Setup
> Switchgear.
Table 5–27: SWITCHGEAR SETTINGS
RESET (KI)
2
t COUNTERS (KI)
2
t Counters reset signal. This signal is configured at Setpoint > Relay Configuration > Protection
Elements, and it is used for resetting the (KI)
2
t counter through the corresponding signal, command,
digital input, etc.
RESET BKR COUNTERS Reset signal for the Opening and Closing Counters. This signal is configured at Setpoint > Relay
Configuration > Protection Elements, and it is used for resetting the breaker Opening and closing
counters.
BREAKER OPENINGS Number of Breaker openings
BREAKER CLOSINGS Number of Breaker closings
(KI)
2
t PHASE A Accumulated (KI)
2
t value for phase A ((KI)
2
t Counter for Phase A)
(KI)
2
t PHASE B Accumulated (KI)
2
t value for phase B ((KI)
2
tCounter for Phase B)
(KI)
2
t PHASE C Accumulated (KI)
2
t value for phase C ((KI)
2
t Counter for Phase C)
BKR OPENING TIME Maximum breaker Opening time. This signal is configured at Setpoint > Relay Configuration
>Switchgear in the number of switchgear corresponding to the breaker selection
BKR CLOSING TIME Maximum breaker Closing time. This signal is configured at Setpoint > Relay Configuration
>Switchgear in the number of switchgear corresponding to the breaker selection
SETPOINT > SYSTEM SETUP > SWITCHGEAR
setting Description Name Default
Value
Step Range
Snapshot Event generation for switchgear #1 Snapshot Events SWGR 1 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #2 Snapshot Events SWGR 2 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #3 Snapshot Events SWGR 3 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #4 Snapshot Events SWGR 4 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #5 Snapshot Events SWGR 5 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #6 Snapshot Events SWGR 6 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #7 Snapshot Events SWGR 7 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #8 Snapshot Events SWGR 8 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #9 Snapshot Events SWGR 9 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #10 Snapshot Events SWGR 10 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #11 Snapshot Events SWGR 11 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #12 Snapshot Events SWGR 12 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #13 Snapshot Events SWGR 13 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #14 Snapshot Events SWGR 14 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #15 Snapshot Events SWGR 15 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #16 Snapshot Events SWGR 16 DISABLED N/A [DISABLED – ENABLED]
