6.2.5 PROTECTION SUMMARY
Actual > Status > Protection Summary . This screen shows a complete listing of all protection and control elements in
the relay, showing their status (enabled or not) through the corresponding LED . Table 6–17:
Phase IOC1 High
Phase IOC2 High
Phase IOC3 High
Phase IOC1 Low
Phase IOC2 Low
Phase IOC3 Low
Neutral IOC1
Neutral IOC2
Neutral IOC3
Ground IOC1
Ground IOC2
Ground IOC3
Sensitive Ground IOC1
Sensitive Ground IOC2
Sensitive Ground IOC3
Phase TOC1 High
Phase TOC2 High
Phase TOC3 High
Neutral TOC1
Neutral TOC2
Neutral TOC3
Ground TOC1
Ground TOC2
Ground TOC3
Sensitive Ground TOC1
Sensitive Ground TOC2
Sensitive Ground TOC3
Phase UV1
Phase UV2
Phase UV3
Phase UV4
Phase Directional1
Phase Directional2
Phase Directional3
Neutral Directional1
Neutral Directional2
Neutral Directional3
Ground Directional1
Ground Directional2
Ground Directional3
Breaker Failure
Fuse Failure
Recloser
Neutral OV1 High
Neutral OV2 High
Neutral OV3 High
Neutral OV1 Low
Neutral OV2 Low
Neutral OV3 Low
