7.2.5 DATASETS
Datasets are used for the Reports. When any element change, this information will be send spontaneously to the clients.
7.2.5.1 MEASUREMENT DATASET.
NAME REFERENCE
Phase Real Pwr Value MMXU1$MX$TotW$mag$f
Phase Real Pwr quality MMXU1$MX$TotW$q
Phase Real Pwr time MMXU1$MX$TotW$t
Phase Reactive Pwr Value MMXU1$MX$TotVar$mag$f
Phase Reactive Pwr quality MMXU1$MX$TotVar$q
Phase Reactive Pwr time MMXU1$MX$TotVar$t
Phase Apparent Pwr Value MMXU1$MX$TotVa$mag$f
Phase Apparent Pwr quality MMXU1$MX$TotVa$q
Phase Apparent Pwr time MMXU1$MX$TotVa$t
Average Power Factor Value MMXU1$MX$TotPF$mag$f
Average Power Factor quality MMXU1$MX$TotPF$q
Average Power Factor time MMXU1$MX$TotPF$t
Frequency Value MMXU1$MX$Hz$mag$f
Frequency quality MMXU1$MX$Hz$q
Frequency time MMXU1$MX$Hz$t
Phase A to Phase B Voltage Value MMXU1$MX$PPV$phsAB$cVal$mag$f
Phase A to Phase B Voltage quality MMXU1$MX$PPV$phsAB$q
Phase A to Phase B Voltage time MMXU1$MX$PPV$phsAB$t
Phase B to Phase C Voltage Value MMXU1$MX$PPV$phsBC$cVal$mag$f
Phase B to Phase C Voltage quality MMXU1$MX$PPV$phsBC$q
Phase B to Phase C Voltage time MMXU1$MX$PPV$phsBC$t
Phase C to Phase A Voltage Value MMXU1$MX$PPV$phsCA$cVal$mag$f
Phase C to Phase A Voltage quality MMXU1$MX$PPV$phsCA$q
Phase C to Phase A Voltage time MMXU1$MX$PPV$phsCA$t
Phase A to Ground Voltage Value MMXU1$MX$PhV$phsA$cVal$mag$f
Phase A to Ground Voltage quality MMXU1$MX$PhV$phsA$q
Phase A to Ground Voltage time MMXU1$MX$PhV$phsA$t
Phase B to Ground Voltage Value MMXU1$MX$PhV$phsB$cVal$mag$f
Phase B to Ground Voltage quality MMXU1$MX$PhV$phsB$q
Phase B to Ground Voltage time MMXU1$MX$PhV$phsB$t
Phase C to Ground Voltage Value MMXU1$MX$PhV$phsC$cVal$mag$f
Phase C to Ground Voltage quality MMXU1$MX$PhV$phsC$q
Phase C to Ground Voltage time MMXU1$MX$PhV$phsC$t
Neutral Voltage Value MMXU1$MX$PhV$res$cVal$mag$f
Neutral Voltage quality MMXU1$MX$PhV$res$q
Neutral Voltage time MMXU1$MX$PhV$res$t
Phase A Current Value MMXU1$MX$A$phsA$cVal$mag$f
Phase A Current quality MMXU1$MX$A$phsA$q
Phase A Current time MMXU1$MX$A$phsA$t
Phase B Current Value MMXU1$MX$A$phsB$cVal$mag$f
Phase B Current quality MMXU1$MX$A$phsB$q
Phase B Current time MMXU1$MX$A$phsB$t
Phase C Current Value MMXU1$MX$A$phsC$cVal$mag$f
Phase C Current quality MMXU1$MX$A$phsC$q
Phase C Current time MMXU1$MX$A$phsC$t
