GEK-113032A W650 Wind Generator Protection System 7-29
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR W650
7
7.2.3.6 LOGICAL NODES FOR SWITCHGEAR. LN GROUP: X
b) XCBR (CIRCUIT BREAKER)
7.2.4 COMMON DATA CLASS
7.2.4.1 COMMON DATA CLASS SPECIFICATIONS FOR STATUS INFORMATION
a) SINGLE POINT STATUS (SPS)
XCBR class
Attribute
Name
Attr.
Type
Explanation M/O Notes
XCBR Circuit breaker
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M Number of Switchgear
Loc geSPS Local operation M Local / Remote
OpCnt geINS Operation counter M Breaker openings
Controls
Pos geDPC Switch position M Breaker open, close, und
BlkOpn geSPC Block opening M Virtual output
BlkClr geSPC Block closing M Virtual output
Status information
CBOpCap geINS Cicruit breaker operating capability M (BKR Openings Cnt –
BREAKER Openings)*2
Metered Values
SmSwARs geBCR Sum of Switched Amperes, reseteable O
Settings
ThAlSwA geFloatASG Threshold Alarm of Switched Amps P Maximum KI2t
SumSwATmms geFloatASG Sum of sw. Amps integration time P KI2t Integ. Time
ExNumTr geIntASG Excessive number of trips P Maximum Openings
ExNumTr1hr geIntASG Excessive number of trips in 1 hour P Max. Openings 1 hour
SPS CLASS (SINGLE POINT STATUS)
GESPS
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
status
stVal Boolean ST dchg M
q BVstring13 ST qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
