7-30 W650 Wind Generator Protection System GEK-113032A
7.2 IEC 61850 PROFILE FOR W650 7 IEC 61850 PROTOCOL
7
b) 3.1.2 INTEGER STATUS (INS)
INS CLASS (INTEGER STATUS)
GEINS
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
status
stVal INT32 ST dchg M
q BVstring13 ST qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
GEINS_AR
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
status
stVal Enum ST dchg (Out of Service, Ready, Lockout,
Block, Reclose in progress)
M
q BVstring13 ST qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
GEINS_AR_LO
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
status
stVal Enum ST dchg (None, Anomaly, Fail to Open, Fail to
close, Manual, No conditions, Max
number of trips, last shot )
M
q BVstring13 ST qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
GEINS_AR_BLK
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
status
stVal Enum ST dchg ( None, level, pulse, level+pulse ) M
q BVstring13 ST qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
