GEK-113032A W650 Wind Generator Protection System 7-31
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR W650
7
c) PROTECTION ACTIVATION INFORMATION (ACT)
ACT CLASS (PROTECTION ACTIVATION INFORMATION)
GEPHSACT
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
control and status
general Boolean ST Dchg M
phsA Boolean ST Dchg O
phsB Boolean ST Dchg O
phsC Boolean ST Dchg O
q Bvstring13 ST Qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
GENEUTACT
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
control and status
general Boolean ST Dchg M
neut Boolean ST Dchg O
q Bvstring13 ST Qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
GEGENERALACT
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
control and status
general Boolean ST Dchg M
q BVstring13 ST Qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
