7-32 W650 Wind Generator Protection System GEK-113032A
7.2 IEC 61850 PROFILE FOR W650 7 IEC 61850 PROTOCOL
7
d) 3.1.4 DIRECTIONAL PROTECTION ACTIVATION INFORMATION (ACD)
ACD CLASS (DIRECTIONAL PROTECTION ACTIVATION INFORMATION)
GEPHSACD
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
control and status
general Boolean ST Dchg M
DirGeneral Enumerated (Byte) ST Dchg unknown | forward | backward | both M
PhsA Boolean ST Dchg GC_2(1)
DirPhsA Enumerated (Byte) ST dchg unknown | forward | backward GC_2(1)
PhsB Boolean ST dchg GC_2(2)
DirPhsB Enumerated (Byte) ST dchg unknown | forward | backward GC_2(2)
PhsC Boolean ST dchg GC_2(3)
DirPhsC Enumerated (Byte) ST dchg unknown | forward | backward GC_2(3)
q Bvstring13 ST qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
GENEUTACD
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
control and status
general Boolean ST dchg M
DirGeneral Enumerated (Byte) ST dchg unknown | forward | backward | both M
neut Boolean ST dchg GC_2(4)
DirNeut Enumerated (Byte) ST dchg unknown | forward | backward GC_2(4)
q BVstring13 ST qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
GEGENERALACD
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
control and status
general Boolean ST dchg M
DirGeneral Enumerated (Byte) ST dchg unknown | forward | backward | both M
q BVstring13 ST qchg M
t Utctime ST M
configuration, descripcion and extension
d Vstring255 DC O
