GEK-113032A W650 Wind Generator Protection System 7-33
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR W650
7
e) BINARY COUNTER READING (BCR).
7.2.4.2 COMMON DATA CLASS SPECIFICATIONS FOR MEASURAND INFORMATION
a) MEASURED VALUE (MV)
BCR CLASS (BINARY COUNTER READING)
GEBCR
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DataAttribute
control and status
ActVal INT32 ST dchg M
q BVstring13 ST qchg M
t Utctime ST M
configuration, descripcion and extension
units
SIUnit
multiplier
Unit CF O
Byte M
Byte O
PulsQty FLOAT32 CF M
d Vstring255 DC O
MV CLASS (MEASURED VALUE)
GEMV (CON LOS 2 VALORES INT32 Y FLOAT32)
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
measured attributes
Mag
i
AnalogueValue MX dchg M
INT32 GC_1
f FLOAT32 GC_1
q BVstring13 MX qchg M
t Utctime MX M
Configuration, descripcion and extension
units
SIUnit
multiplier
Unit CF O
ENUMERATED(Byte) M
ENUMERATED(Byte) O
d Vstring255 DC O
GEFLOATMV (EL VALOR SOLO EN FLOAT32)
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C
