GEK-113032A W650 Wind Generator Protection System 4-3
4 HUMAN INTERFACES. 4.1 ENERVISTA 650 SETUP SOFTWARE INTERFACE
4
4.1.3 MAIN SCREEN
The EnerVista 650 Setup software main window supports the following primary display components:
• Title bar
• Main menu bar
• Main icon bar
• Working area
• Status bar
Figure 4–1: ENERVISTA 650 SETUP MAIN SCREEN
Working Area
Main Menu bar
Main Icon bar
Title
Status bar
