GEK-113032A W650 Wind Generator Protection System 8-7
8 W650 CANOPEN PROFILE 8.4 OBJECT DICTIONARY
8
8.4.2 MANUFACTURER SPECIFIC OBJECTS
MANUFACTURER SPECIFIC OBJECTS
INDEX OBJECT SUB-INDEX NAME TYPE ATTR DEFAULT
2000h VAR 0 Multiplexed Data UNSIGNED64 RO 0
VALUE OF
OBJECT
2000H
WORD 0 WORD 1 WORD 2 WORD 3
HB LB HB LB HB LB HB LB
1 Mux DDh f grid Exp U LxN Exp I Lx Exp Px/Qx -
2 Mux DDh U L1N U L2N U L3N
3 Mux DDh IL1 IL2 IL3
4 Mux DDh P Q Cos Phi
VALUE SCALING UNIT TYPE MIN MAX
Mux - - Unsigned8 1 4
f grid 1/100 Hz Unsigned16 - -
Exp U LxN - - Integer8 - -
Exp I Lx - - Integer8 - -
Exp Px/Qx - - Integer8 - -
U L1N - V Unsigned16 0 9999
U L2N - V Unsigned16 0 9999
U L3N - V Unsigned16 0 9999
IL1 - A Unsigned16 0 9999
IL2 - A Unsigned16 0 9999
IL3 - A Unsigned16 0 9999
P - W Integer16 -9999 9999
Q - var Integer16 -9999 9999
Cos Phi 1/100 - Integer16 -99 100
