4.1.6 ENERVISTA 650 SETUP MENUS STRUCTURE
The EnerVista 650 Setup menus structure is shown in Table 4–3: .
Unless specified, options are available in both On-line and Off-line mode.
Options enabled only in On-line mode are marked as (*)
Options enabled only in Off-line mode are marked as (**)
The “View > Language” submenu allows the user to change the default language for the EnerVista 650 Setup program and
it is only enabled when the relay is not communicating and no file has been opened.
Table 4–3: ENERVISTA 650 SETUP MENUS STRUCTURE
FILE SETPOINT ACTUAL
OPERATIONS
(*)
COMMUNICATION SECURITY VIEW HELP
Open (**) Product Setup Front Panel NA Computer Login user Traces
Instruction
Manual
Save As
(**)
System Setup Status NA Modem (*)
Change
Password
ModBus
Memory
Map
About
EnerVista
650 Setup
Close (**)
Protection
Elements
Metering NA Troubleshooting (*)
User
Management
Languages
(**)
Config File
Converter
Control
Elements
Inputs/Outputs NA Calibration (*)
Properties
(**)
Inputs/Outputs Records (*) NA
Upgrade firmware
version (*)
Get info
from relay
(*)
Relay
Configuration
NA
Upgrade operating
system (*)
Send info
to relay (*)
Logic
Configuration
NA
Upgrade 650 Web
Server
Print Setup
(**)
Clock (*) NA
Upload info files to
relay
Print
Preview
(**)
NA
Download info files
from relay
Print (**) NA
Print to file
(**)
NA
Exit NA
