6-12 W650 Wind Generator Protection System GEK-113032A
6.2 STATUS 6 ACTUAL VALUES
6
6.2.4.5 SETTING GROUPS
This screen can be accessed at Actual> Status > Control Elements > Setting Groups, and it includes activation and
block signals for the relay setting groups change in the following signaling LEDs:
Table 6–16: SETTING GROUP ACTUAL VALUES
SETTING GROUPS ACTUAL VALUES
GROUP 1 ACT ON
GROUP 2 ACT ON
GROUP 3 ACT ON
GROUP 4 ACT ON
GROUP 1 BLOCKED
GROUP 2 BLOCKED
GROUP 3 BLOCKED
GROUP 4 BLOCKED
