5.2.1.5 IEC 60870-5-104
Communication settings for IEC 60870-5-104 protocol. For more detailed information go to appendix D in this manual.
Table 5–6: IEC 60870-5-104 PROTOCOL SETTINGS
5.2.1.6 CAN OPEN
Communication settings for CANopen protocol. For more detailed information go to chapter 8 W650 CANOPEN PROFILE
in this manual.
Table 5–7: CAN OPEN PROTOCOL SETTINGS
5.2.1.7 SNTP
Table 5–8: SNTP PROTOCOL SETTINGS
PRODUCT SETUP>COMMUNICATION SETTINGS >DNP3 SLAVE
DNP3 SLAVE 1 > DNP3 SLAVE 2 > DNP3 SLAVE 3
Binary Input Block 6 CTL EVENTS 81-96 N/A
Binary Input Block 7 CTL EVENTS 97-112 N/A
Binary Input Block 8 CTL EVENTS 113-128 N/A
Binary Input Block 9 SWITCHGEAR 1-8 N/A
Binary Input Block 10 SWITCHGEAR 9-16 N/A
PRODUCT SETUP>COMMUNICATION SETTINGS >IEC 870-5-104
Name Default Value Step Range
Function DISABLED N/A [DISABLED – ENABLED]
TCP Port 2404 1 [0 : 65535]
Common Addr of ASDU 255 1 [0 : 65535]
Cyclic Meter Period 0 1 [0 : 3600]
Synchronization Event 0 1 [0 : 3600]
PRODUCT SETUP>COMMUNICATION SETTINGS >CAN OPEN
Name Default Value Step Range
CANOpen Nodeld 1 1 [1 – 127]
CANOpen Baud 125 kbps N/A [125 : 500 kbps]
PRODUCT SETUP>COMMUNICATION SETTINGS >SNTP
Name Default Value Step Range
Function DISABLED N/A [DISABLED – ENABLED]
UDP Port 123 1 [0 : 65535]
Server Ip Oct1 0 1 [0 : 255]
Server Ip Oct2 0 1 [0 : 255]
Server Ip Oct3 0 1 [0 : 255]
Server Ip Oct4 0 1 [0 : 255]
