5-90 W650 Wind Generator Protection System GEK-113032A
5.6 INPUTS/OUTPUTS 5 SETTINGS
5
For the I/O board selection in the relay model, associated digits to each board type are as follows:
Table 5–78: I/O BOARD TYPE
CCY Is the name used for inputs in I/O boards
0Z Is the name used for the different outputs in I/O boards
ASSOCIATED DIGIT ENERVISTA 650 Setup BOARD settingS BOARD TYPE
0 NONE None
1 16 INP+ 8OUT Mixed
2 8 INP +8 OUT +SUPV Supervision
4 32 INP 32 digital inputs
5 16 INP + 8 ANA 8 Analog Inputs + 16 digital
inputs
