GEK-113032A W650 Wind Generator Protection System 5-121
5 SETTINGS 5.8 RELAY CONFIGURATION
5
Table 5–89: GRAPHIC AND TEXT EDITION SYMBOLS
GRAPHIC AND TEXT EDITION SYMBOLS
ICONS IN SCREEN DESCRIPTION
Ground symbols in different positions.
Transformers representation
Symbols reserved for future uses
Symbol for capacitor banks.
Symbol for wye connection
Symbol for open delta and delta connection
Display of a fix text up to 40 ASCII characters
Auxiliary drawing lines
