GEK-113032A W650 Wind Generator Protection System 6-9
6 ACTUAL VALUES 6.2 STATUS
6
The AUTORECLOSE INPUTS are signal configurable by the user at Setpoint > Relay Configuration > Protection
Elements to:
AR LEVEL BLOCK: programmable signal to block the autoreclose unit by level
AR PULSE BLOCK: programmable signal to block the autoreclose unit by pulse
AR PULSE UNBLOCK: programmable signal to unblock the autoreclose unit by pulse
AR INITIATE: programmable signal to initiate the autoreclose.
AR CONDS INPUT: programmable signal to set the conditions to be met before executing a breaker close.
AR BLOCK BY LEVEL
AR BLOCK BY PULSE
AR STATUS
AR LOCKOUT MODE
AR BLOCK MODE
