7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR W650
7
b) COMPLEX MEASURED VALUE (MV)
CMV CLASS (COMPLEX MEASURED VALUE)
GEINTCMV (EL VALOR SOLO EN INT32)
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
measured attributes
instCVal
mag
i
geIntVector MX dchg O
geIntAnalogValue
INT32
cVal
mag
i
geIntVector MX dchg M
geIntAnalogValue
INT32
q BVstring13 MX qchg M
t Utctime MX M
configuration, descripcion and extension
units
SIUnit
multiplier
Unit CF O
Byte M
Byte O
Db INT32U CF O
magSVC
scaleFactor
offset
ScaledValueConfig CF AC_SCAV
FLOAT32 M
FLOAT32 M
d Vstring255 DC O
GEFLOATCMV (EL VALOR SOLO EN INT32)
Attribute
Name
Attribute Type FC TrgOp Value/Value Range M/O/C
DATAATTRIBUTE
measured attributes
instCVal
mag
f
geFloatVector MX dchg O
geFloatAnalogValue
FLOAT32
cVal
mag
i
geFloatVector MX dchg M
geFloatAnalogValue
FLOAT32
q BVstring13 MX qchg M
t Utctime MX M
configuration, descripcion and extension
units
SIUnit
multiplier
Unit CF O
Byte M
Byte O
Db INT32U CF O
magSVC
scaleFactor
offset
ScaledValueConfig CF AC_SCAV
FLOAT32 M
FLOAT32 M
d Vstring255 DC O
