GEK-113032A W650 Wind Generator Protection System A-9
APPENDIX A A.1 LOGIC OPERANDS
A
OPERANDS - 650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
Phase IOC Low
PH IOC3 LOW PKP
Phase instantaneous overcurrent element pickup low
level Group 3 any phase
PH IOC3 LOW OP
Phase instantaneous overcurrent element operation
(trip) low level Group 3 any phase
Neutral IOC
NEUTRAL IOC1 BLOCK
Neutral instantaneous overcurrent element block Group
1
NEUTRAL IOC1 PKP
Neutral instantaneous overcurrent element pickup
Group 1
NEUTRAL IOC1 OP
Neutral instantaneous overcurrent element operation
(trip) Group 1
NEUTRAL IOC2 BLOCK
Neutral instantaneous overcurrent element block Group
2
NEUTRAL IOC2 PKP
Neutral instantaneous overcurrent element pickup
Group 2
NEUTRAL IOC2 OP
Neutral instantaneous overcurrent element operation
(trip) Group 2
NEUTRAL IOC3 BLOCK
Neutral instantaneous overcurrent element block Group
3
NEUTRAL IOC3 PKP
Neutral instantaneous overcurrent element pickup
Group 3
NEUTRAL IOC3 OP
Neutral instantaneous overcurrent element operation
(trip) Group 3
Ground IOC
GROUND IOC1 BLOCK
Ground instantaneous overcurrent element block Group
1
GROUND IOC1 PKP
Ground instantaneous overcurrent element pickup
Group 1
GROUND IOC1 OP
Ground instantaneous overcurrent element operation
(trip) Group 1
GROUND IOC2 BLOCK
Ground instantaneous overcurrent element block Group
2
GROUND IOC2 PKP
Ground instantaneous overcurrent element pickup
Group 2
GROUND IOC2 OP
Ground instantaneous overcurrent element operation
(trip) Group 2
GROUND IOC3 BLOCK
Ground instantaneous overcurrent element block Group
3
GROUND IOC3 PKP
Ground instantaneous overcurrent element pickup
Group 3
GROUND IOC3 OP
Ground instantaneous overcurrent element operation
(trip) Group 3
Sensitive Ground IOC
SENS GND IOC1 BLK
Sensitive ground instantaneous overcurrent element
block Group 1
SENS GND IOC1 PKP
Sensitive ground instantaneous overcurrent element
pickup Group 1
SENS GND IOC1 OP
Sensitive ground instantaneous overcurrent element
operation (trip) Group 1
SENS GND IOC2 BLK
Sensitive ground instantaneous overcurrent element
block Group 2
SENS GND IOC2 PKP
Sensitive ground instantaneous overcurrent element
pickup Group 2
SENS GND IOC2 OP
Sensitive ground instantaneous overcurrent element
operation (trip) Group 2
SENS GND IOC3 BLK
Sensitive ground instantaneous overcurrent element
block Group 3
SENS GND IOC3 PKP
Sensitive ground instantaneous overcurrent element
pickup Group 3
SENS GND IOC3 OP
Sensitive ground instantaneous overcurrent element
operation (trip) Group 3
