A-18 W650 Wind Generator Protection System GEK-113032A
A.1 LOGIC OPERANDS APPENDIX A
A
OPERANDS - 650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
Neutral OV High
NEUTRAL OV1 HIGH
BLK
Neutral overvoltage element block high level Group 1
NEUTRAL OV1 HIGH
PKP
Neutral overvoltage element pickup high level Group 1
NEUTRAL OV1 HIGH
OP
Neutral overvoltage element operation high level Group
1
NEUTRAL OV2 HIGH
BLK
Neutral overvoltage element block high level Group 2
NEUTRAL OV2 HIGH
PKP
Neutral overvoltage element pickup high level Group 2
NEUTRAL OV2 HIGH
OP
Neutral overvoltage element operation high level Group
2
NEUTRAL OV3 HIGH
BLK
Neutral overvoltage element block high level Group 3
NEUTRAL OV3 HIGH
PKP
Neutral overvoltage element pickup high level Group 3
NEUTRAL OV3 HIGH
OP
Neutral overvoltage element operation high level Group
3
Neutral OV Low
NEUTRAL OV1 LOW
BLK
Neutral overvoltage element block low level Group 1
NEUTRAL OV1 LOW
PKP
Neutral overvoltage element pickup low level Group 1
NEUTRAL OV1 LOW
OP
Neutral overvoltage element operation low level Group
1
NEUTRAL OV2 LOW
BLK
Neutral overvoltage element block low level Group 2
NEUTRAL OV2 LOW
PKP
Neutral overvoltage element pickup low level Group 2
NEUTRAL OV2 LOW
OP
Neutral overvoltage element operation low level Group
2
NEUTRAL OV3 LOW
BLK
Neutral overvoltage element block low level Group 3
NEUTRAL OV3 LOW
PKP
Neutral overvoltage element pickup low level Group 3
NEUTRAL OV3 LOW
OP
Neutral overvoltage element operation low level Group
3
Auxiliary UV
AUXILIARY UV1 BLOCK Auxiliary undervoltage element block Group 1
AUXILIARY UV1 PKP Auxiliary undervoltage element pickup Group 1
AUXILIARY UV1 OP Auxiliary undervoltage element operation Group 1
AUXILIARY UV2 BLOCK Auxiliary undervoltage element block Group 2
AUXILIARY UV2 PKP Auxiliary undervoltage element pickup Group 2
AUXILIARY UV2 OP Auxiliary undervoltage element operation Group 2
AUXILIARY UV3 BLOCK Auxiliary undervoltage element block Group 3
AUXILIARY UV3 PKP Auxiliary undervoltage element pickup Group 3
AUXILIARY UV3 OP Auxiliary undervoltage element operation Group 3
Auxiliary OV
AUXILIARY OV1 BLOCK Auxiliary overvoltage element block Group 1
AUXILIARY OV1 PKP Auxiliary Overvoltage element pickup Group 1
AUXILIARY OV1 OP Auxiliary overvoltage element operation Group 1
AUXILIARY OV2 BLOCK Auxiliary overvoltage element block Group 2
AUXILIARY OV2 PKP Auxiliary Overvoltage element pickup Group 2
AUXILIARY OV2 OP Auxiliary overvoltage element operation Group 2
AUXILIARY OV3 BLOCK Auxiliary overvoltage element block Group 3
AUXILIARY OV3 PKP Auxiliary Overvoltage element pickup Group 3
AUXILIARY OV3 OP Auxiliary overvoltage element operation Group 3
