GEK-113032A W650 Wind Generator Protection System A-21
APPENDIX A A.1 LOGIC OPERANDS
A
OPERANDS - 650 - MODEL FX - GX
INTERNAL SYSTEM STATUS (CONT.)
Directional Power
DIR PWR1 BLOCK Directional power element block Group 1
DIR PWR1 STG1 PKP Directional Power element pickup level 1 Group 1
DIR PWR1 STG1 OP Directional Power element operation level 1 Group 1
DIR PWR1 STG2 PKP Directional Power element pickup level 2 Group 1
DIR PWR1 STG2 OP Directional Power element operation level 2 Group 1
DIR PWR1 STG PKP Directional power element pickup Group 1
DIR PWR1 STG OP Directional Power element operation Group 1
DIR PWR2 BLOCK Directional power element block Group 2
DIR PWR2 STG1 PKP Directional Power element pickup level 1 Group 2
DIR PWR2 STG1 OP Directional Power element operation level 1 Group 2
DIR PWR2 STG2 PKP Directional Power element pickup level 2 Group 2
DIR PWR2 STG2 OP Directional Power element operation level 2 Group 2
DIR PWR2 STG PKP Directional power element pickup Group 2
DIR PWR2 STG OP Directional Power element operation Group 2
DIR PWR3 BLOCK Directional power element block Group 3
DIR PWR3 STG1 PKP Directional Power element pickup level 1 Group 3
DIR PWR3 STG1 OP Directional Power element operation level 1 Group 3
DIR PWR3 STG2 PKP Directional Power element pickup level 2 Group 3
DIR PWR3 STG2 OP Directional Power element operation level 2 Group 3
DIR PWR3 STG PKP Directional power element pickup Group 3
DIR PWR3 STG OP Directional Power element operation Group 3
DIR PWR4 BLOCK Directional power element block Group 4
DIR PWR4 STG1 PKP Directional Power element pickup level 1 Group 4
DIR PWR4 STG1 OP Directional Power element operation level 1 Group 4
DIR PWR4 STG2 PKP Directional Power element pickup level 2 Group 4
DIR PWR4 STG2 OP Directional Power element operation level 2 Group 4
DIR PWR4 STG PKP Directional power element pickup Group 4
DIR PWR4 STG OP Directional Power element operation Group 4
Remote Outputs
DNA 1 1 output on. Remote Output DNA 1 Operation
DNA 2 1 output on. Remote Output DNA 1 Operation
... ...
DNA 32 1 output on. Remote Output DNA 1 Operation
User St 1 1 output on. Remote Output UserSt 1 Operation
User St 2 1 output on. Remote Output UserSt 1 Operation
... ...
User St 64 1 output on. Remote Output UserSt 1 Operation
Remote Inputs
Remote Input 1 Flag is set, logic =1
Remote Input 2 Flag is set, logic =1
... ...
Remote Input 32 Flag is set, logic =1
Remote Devices
Remote Device 1 Flag is set, logic =1
Remote Device 2 Flag is set, logic =1
... ...
Remote Device 16 Flag is set, logic =1
