B-36 W650 Wind Generator Protection System GEK-113032A
B.7 MEMORY MAP APPENDIX B
B
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
LEDS HMI (16 elementos) - HMI Leds (cont.)
0x00D2 0x0100 LED 10 F001 R 1
0x00D2 0x0200 LED 11 F001 R 1
0x00D2 0x0400 LED 12 F001 R 1
0x00D2 0x0800 LED 13 F001 R 1
0x00D2 0x1000 LED 14 F001 R 1
0x00D2 0x2000 LED 15 F001 R 1
Teclas HMI - HMI Keys
0x00D2 0x4000 I Key F001 R 1
0x00D2 0x8000 O Key F001 R 1
0x00D2 0x0001 * Key F001 R 1
0x00D2 0x0002 F1 Key F001 R 1
0x00D2 0x0004 F2 Key F001 R 1
0x00D2 0x0008 LOCAL OPERATION MODE F001 R 1
0x00D2 0x0010 OPERATIONS BLOCKED F001 R 1
Estados Internos - Internal States
0x00D2 0x0020 DSP COMM ERROR F001 R 1
0x00D2 0x0040 MAGNETIC MODULE ERROR F001 R 1
Entrada Reset Leds (configurable) -Led reset Input
0x00D2 0x0080 LED RESET INPUT F001 R 1
Sobrecorriente instantanea de fases nivel alto - Phase IOC High
0x00F2 0x0080 PH IOC1 HIGH A BLK F001 R 1
0x00F3 0x0100 PH IOC1 HIGH B BLK F001 R 1
0x00F3 0x0200 PH IOC1 HIGH C BLK F001 R 1
0x00F3 0x0400 PH IOC1 HIGH A PKP F001 R 1
0x00F3 0x0800 PH IOC1 HIGH A OP F001 R 1
0x00F3 0x1000 PH IOC1 HIGH B PKP F001 R 1
0x00F3 0x2000 PH IOC1 HIGH B OP F001 R 1
0x00F3 0x4000 PH IOC1 HIGH C PKP F001 R 1
0x00F3 0x8000 PH IOC1 HIGH C OP F001 R 1
0x00F3 0x0001 PH IOC1 HIGH PKP F001 R 1
0x00F3 0x0002 PH IOC1 HIGH OP F001 R 1
0x00F8 0x0004 PH IOC2 HIGH A BLK F001 R 1
0x00F8 0x0008 PH IOC2 HIGH B BLK F001 R 1
0x00F8 0x0010 PH IOC2 HIGH C BLK F001 R 1
0x00F8 0x0020 PH IOC2 HIGH A PKP F001 R 1
0x00F8 0x0040 PH IOC2 HIGH A OP F001 R 1
0x00F8 0x0080 PH IOC2 HIGH B PKP F001 R 1
0x00F9 0x0100 PH IOC2 HIGH B OP F001 R 1
0x00F9 0x0200 PH IOC2 HIGH C PKP F001 R 1
0x00F9 0x0400 PH IOC2 HIGH C OP F001 R 1
0x00F9 0x0800 PH IOC2 HIGH PKP F001 R 1
0x00F9 0x1000 PH IOC2 HIGH OP F001 R 1
0x00FE 0x2000 PH IOC3 HIGH A BLK F001 R 1
0x00FE 0x4000 PH IOC3 HIGH B BLK F001 R 1
0x00FE 0x8000 PH IOC3 HIGH C BLK F001 R 1
0x00FE 0x0001 PH IOC3 HIGH A PKP F001 R 1
0x00FE 0x0002 PH IOC3 HIGH A OP F001 R 1
0x00FE 0x0004 PH IOC3 HIGH B PKP F001 R 1
0x00FE 0x0008 PH IOC3 HIGH B OP F001 R 1
0x00FE 0x0010 PH IOC3 HIGH C PKP F001 R 1
