GEK-113032A W650 Wind Generator Protection System C-5
APPENDIX C C.2 DNP 3.0 DEVICE PROFILE DOCUMENT
C
b) DNP V3.00 DEVICE PROFILE DOCUMENT (SHEET 2 OF 3)
Requires Application Layer Confirmation:
Never
Always
a When reporting Event Data
a When sending multi-fragment responses
Sometimes
Configurable
Timeouts while waiting for:
Data Link Confirm:
Complete Appl. Fragment:
Application Confirm:
Complete Appl. Response
None
a None
None
a No0ne
a Fixed at 3 s
Fixed at
a Fixed at 4 s
Fixed at
Variable
Variable
Variable
Variable
Configurable
Configurable
Configurable
Configurable
Others:
Transmission Delay:
Need Time Delay:
Select/Operate Arm Timeout:
Binary Input change scanning period:
Packed binary change process period:
Analog Input change scanning period:
Unsolicited response notification delay:
Unsolicited response retry delay:
Unsolicited offline interval:
No intentional delay
10 min.
10 s
1 ms
1 s
500 ms
500 ms
Configurable 0 to 60 s
10 min.
Sends/Executes Control Operations:
WRITE Binary Outputs
SELECT/OPERATE
DIRECT OPERATE
DIRECT OPERATE – NO ACK
a Never
Never
Never
Never
Always
a Always
a Always
a Always
Sometimes
Sometimes
Sometimes
Sometimes
Configurable
Configurable
Configurable
Configurable
Count > 1
Pulse On
Pulse Off
Latch On
Latch Off
a Never
Never
a Never
a Never
a Never
Always
a Always
Always
Always
Always
Sometimes
Sometimes
Sometimes
Sometimes
Sometimes
Configurable
Configurable
Configurable
Configurable
Configurable
Queue
Clear Queue
a Never
a Never
Always
Always
Sometimes
Sometimes
Configurable
Configurable
To Next Page
