GEK-113032A W650 Wind Generator Protection System E-17
APPENDIX E E.2 FACTORY DEFAULT CONFIGURATION
E
E.2FACTORY DEFAULT CONFIGURATION
W650 relays are not preconfigured by default in factory. The list below includes all the configuration possibilities for outputs,
commands, etc.
NOTE:
SOURCE COLUMN:
This columns allow selecting the simple or complex (OR signal or Virtual output) operand that actives the selected
elements on relay configuration
If more than one operands are selected, the relay performs an OR gate with them to activate the selected element.
SIGNAL LOGIC COLUMN:
Refers to each individual signal selected on its left. NOT legend means that the refered signal is inverted
SOURCE LOGIC COLUMN:
Refers to the whole SOURCE signal selected on its left. NOT legend means that SOURCE signal is inverted
If more than one operand were selected, the OR gate output is inverted
SETPOINT>RELAY CONFIGURATION>OUTPUTS
OUTPUT ID OUTPUT NAME SOURCE SIGNAL LOGIC SOURCE LOGIC
CONT OP OPER_F_01 Not Configured
CONT OP OPER_F_02 Not Configured
CONT OP OPER_F_03 Not Configured
CONT OP OPER_F_04 Not Configured
CONT OP OPER_F_05 Not Configured
CONT OP OPER_F_06 Not Configured
CONT OP OPER_F_07 Not Configured
CONT OP OPER_F_08 Not Configured
CONT OP OPER_G_01 Not Configured
CONT OP OPER_G_02 Not Configured
CONT OP OPER_G_03 Not Configured
CONT OP OPER_G_04 Not Configured
CONT OP OPER_G_05 Not Configured
CONT OP OPER_G_06 Not Configured
CONT OP OPER_G_07 Not Configured
CONT OP OPER_G_08 Not Configured
CONT OP RESET_F_01 Not Configured
CONT OP RESET_F_02 Not Configured
CONT OP RESET_F_03 Not Configured
CONT OP RESET_F_04 Not Configured
CONT OP RESET_F_05 Not Configured
CONT OP RESET_F_06 Not Configured
CONT OP RESET_F_07 Not Configured
CONT OP RESET_F_08 Not Configured
CONT OP RESET_G_01 Not Configured
CONT OP RESET_G_02 Not Configured
CONT OP RESET_G_03 Not Configured
CONT OP RESET_G_04 Not Configured
CONT OP RESET_G_05 Not Configured
CONT OP RESET_G_06 Not Configured
CONT OP RESET_G_07 Not Configured
To Next Page
