GEK-113032A W650 Wind Generator Protection System E-23
APPENDIX E E.2 FACTORY DEFAULT CONFIGURATION
E
SETPOINT>RELAY CONFIGURATION>CONTROL EVENTS
EVENT NAME SOURCE SIGNAL LOGIC SOURCE LOGIC
EV1 Not Configured
EV2 Not Configured
... ...
EV128 Not Configured
SETPOINT>RELAY CONFIGURATION>SWITCHGEAR
SWITCHGEAR SETTING VALUE/SOURCE SIGNAL LOGIC SOURCE LOGIC
SWITCHGEAR 1
CONTACTS Not Configured
OPENING TIME Not Configured
CLOSING TIME Not Configured
CONTACT A
SOURCE
Not Configured
CONTACT B
SOURCE
Not Configured
OPEN TEXT Not Configured
ALARM Not Configured
CLOSED TEXT Not Configured
ALARM Not Configured
ERROR 00 TEXT Not Configured
ALARM Not Configured
ERROR 11 TEXT Not Configured
ALARM Not Configured
OPENING INIT Not Configured
CLOSING INIT Not Configured
SWITCHGEAR 2
CONTACTS Not Configured
OPENING TIME Not Configured
CLOSING TIME Not Configured
CONTACT A
SOURCE
Not Configured
CONTACT B
SOURCE
Not Configured
OPEN TEXT Not Configured
ALARM Not Configured
CLOSED TEXT Not Configured
ALARM Not Configured
ERROR 00 TEXT Not Configured
ALARM Not Configured
ERROR 11 TEXT Not Configured
ALARM Not Configured
OPENING INIT Not Configured
CLOSING INIT Not Configured
...
... ...
... ...
