SHENZHEN GETECH TECHNOLOGY CO,.LTD
5. Function Testing
The firmware of Me Creator 2 is already uploaded based on Windows 7 operating system, and we have done
debugging to make sure that every part of it can work normally. However, there may be unpredictable
factors during transportation . Please do the following simple test before using it.
5.1 Repetier-Host Test
5.1.1 Motor Test
Before the test, manually set the motors of X / Y / Z axis at the intermediate position of each axis to avoid
accidental collision occurring during the test. There is emergency stop button on the top right corner , or you
can cut off the power directly if anything went wrong. Be prepared for emergency stop.
Open Repetier host and connect the printer. Turn on the power supply. Connect the printer.
Click Home button , then the three axes will move towards the endstop in turn . After they touch the
endstop they will move back for a short distance and then stop the movement.
