Gema OptiCenter OC06 - Technical Data Overview

Rev. 00 04/19
OptiCenter OC06 Product description

17
Technical Data
Electrical data
OptiCenter OC06
Connected load
230 V+E+N
Frequency
50/60 Hz
Protection type
IP54
Approvals
II 3 D
Pneumatic data
OptiCenter OC06
Inlet pressure
min. 6.5 bar
Water vapor content of
compressed air
max. 1.3 g/m³
Oil content of compressed air
max. 0.1 mg/m³
Powder transport
OptiCenter OC06
24 guns
36 guns
Recovery
max. 3.5 kg/min.
OptiSpeeder capacity
6 kg
9 kg
Compressed air consumption
OptiCenter OC06
Max. compressed air
consumption during cleaning (120
seconds)
300-400 Nm³/h
Coating operation
Fluidization OptiSpeeder +
AirMover + process air
15 Nm³/h
Consumption per applicator
5 Nm³/h
Example for 10 applicators
65 Nm³/h
Cleaning operation mode
Cleaning OptiSpeeder
120 Nm³/h
Cleaning OptiFeed hose to
cyclone
120 Nm³/h
Cleaning conveying hose to an
applicator
30 Nm³/h
Example for 6 applicators (for
group size = 6)
180 Nm³/h
