Rev. 00 04/19
76
Maintenance / Repairs OptiCenter OC06
Sieve damage
The sieve can be damaged when backwashing the transport hose.
► Swing out the sieve completely during this cleaning step.
30. Slowly swing out the sieve and clean it with the air gun
31. Press the button on the monocyclone
– The cleaning process is started.
32. Compressed air pulses blow through the hose from the OptiCenter
to the cyclone
The process can be manually stopped and resumed by the
operator.
33. Swing the funnel on the cyclone slowly away and, at the same time,
clean it off with the air gun
34. Clean the inside of the cyclone with the cleaning wand
35. Reconnect the sieve machine and funnel to the cyclone
36. If a new color is to be used: See chapter "Color change" on page 67.
OTHERWISE
37. To switch the OptiCenter to stand-by mode, press and hold the
key for 2 seconds.
38. Store the powder properly
Cleaning with recovery in the powder hopper**
To use this function, parameter 3413 must be set and the optional
“powder recovery system” extension must be installed.
– See chapter "Parameter description" on page 54.
1. End the coating procedure
2. To exit Coating mode, press and hold the key for 2 seconds.
The following menu appears on the display:
