OptiCenter OC06 Fault clearance

91
Fault clearance
Error messages
If faults occur in the powder management center, an error message
shown in red lettering appears on the display.
1
Booth not ready
2
No release for cleaning, X axes not in cleaning position
3
Sieve error or switched off
4
No powder
5
No fresh powder
6
Powder circuit stopped
7
Level sensor detects no powder
The causes of these errors must be eliminated, before further procedures
can be carried out (refer to troubleshooting guide).
If the error has been eliminated, the display returns to the previous menu
again.
Troubleshooting guide
Fault
Cause
Corrective action
No extraction in the
OptiCenter
Incorrect operating mode
selected
Select correct operating mode
Corresponding valve in the
valve pool defective or dirty
Check function at
corresponding output (see also
“Pneumatic diagram”), replace if
necessary
Exhaust air flap does not move
Check for movement or replace
No AirMover function in the
OptiSpeeder
Ring injector clogged or dirty
Clean
Corresponding valve in the
valve pool defective or dirty
Check function at
corresponding output (see also
“Pneumatic diagram”), replace if
necessary
AirMover function in
OptiSpeeder in cleaning
mode too low
Corresponding valve in the
valve pool does not switch
over:
– Defective or dirty
Check function at
corresponding output (see also
“Pneumatic diagram”), replace if
necessary
