Gemalto Prox–DU Reference Manual

Reference Manual
Prox–DU & Prox–SU
www.gemalto.com
DOC118569D Public Use Page 114/145
2 FF
3 09
Usage ID (Vendor defined 01)
4 01
5 A1
Collection (Application)
6 01
7 09
Input Report
Usage ID (Vendor defined 02)
8 02
9 15
Input Report
Logical Minimum (0)
10 00
11 26
Input Report
Logical Maximum (255)
12 FF
13 00
14 75
Input Report
Report Size (8) 8 bits per data
15 08
16 96
Input Report
Report Count (0x116) 278 x8 bits
17 16
18 01
19 81
Input (Data, Variable, Absolute)
20 02
21 09
Output Report
Usage ID (Vendor defined 03)
22 03
23 15
Output Report
Logical Minimum (0)
24 00
25 26
Output Report
Logical Maximum (255)
26 FF
27 00
28 75
Output Report
Report Size (8) 8 bits per data
29 08
30 96
Output Report
Report Count (0x116) 278 x 8bits
31 16
32 01
33 91
Output (Data, Variable, Absolute)
34 02
35 09
Feature Report
Usage ID (Vendor defined 04)
36 04
37 15
Feature Report
Logical Minimum (0)
38 00
39 26
Feature Report
Logical Maximum (255)
40 FF
41 00
42 75
Feature Report
Report Size (8) 8bits per data
43 08
44 96
Feature Report
Report Count (0x116) 278 x 8 bits
45 16
46 01
47 B1
Feature (Data, Variable, Absolute)
48 02
49 C0 End of Collection (Application)
Table 34 – USB HID Report Descriptor
