Gemalto Prox–DU Reference Manual

Reference Manual
Prox–DU & Prox–SU
www.gemalto.com
DOC118569D Public Use Page 81/145
0x80h
9 bChainParameter 1 00h Depends on the exchange level
reported by the class descriptor
in dwFeature field.
TPDU level, Short APDU level,
this field is RFU =00h.
10 abData Byte
array
This field contains the data
returned by the CCID
The response message length = 10 + Card card response length (or ATR length).
The maximum length in case of Short ADPU = 10 + 258 = 268 bytes.
RDR_to_PC_SlotStatus
This message is the response to the PC_to_RDR_IccPowerOff, PC_to_RDR_GetSlotStatus
and PC_to_RDR_Abort commands.
Offset Field Size Value Description
0 bMessageType 1 81h RDR_to_PC_SlotStatus
1 bwLength 4 00000000h
5 bSlot 1 00h Slot number : Same as Bulk-OUT
message
6 bSeq 1 00-FFh Sequence number : Same as Bulk-
OUT message
7 bStatus 1 00h, 01h,
02h, 40h,
41h, 42h
Slot status register:
0Xh = no error
4Xh = command failed
X = 0 card present and active
X = 1 card present and inactive
X = 2 card not present
8 bError 1 00h-FFh Slot error register:
Error when bStatus = 4Xh
9 bClockStatus 1 00h Value =
00h – Clock running
RDR_to_PC_Parameters
This message is the response to the PC_to_RDR_GetParameters,
PC_to_RDR_ResetParameters and PC_to_RDR_SetParameters commands.
Offset Field Size Value Description
0 bMessageType 1 82h RDR_to_PC_Parameters
1 bwLength 4 Size of the
abProtocolDataStructure field
5 bSlot 1 00h Slot number : Same as Bulk-OUT
message
6 bSeq 1 00-FFh Sequence number : Same as Bulk-
OUT message
7 bStatus 1 00h, 01h,
02h, 40h,
41h, 42h
Slot status register:
0Xh = no error
4Xh = command failed
X = 0 card present and active
X = 1 card present and inactive
X = 2 card not present
8 bError 1 00h-FFh Slot error register:
Error when bStatus = 4Xh
9 bProtocolNum 1 00h, 01h Specifies what protocol data
structure follows.
