Reference Manual
Prox–DU & Prox–SU
www.gemalto.com
DOC118569D Public Use Page 118/145
0x02
dwFeatures = 00010230h
00000010h: Automatic ICC clock according to parameters
00000020h: Automatic baud rate according to parameters
00000200h: NAD value other than 00 accepted
00010000h: TPDU level exchanges with CCID
APDU/EMV mode
dwFeatures = 00020472h
00000002h: Automatic parameter configuration based on ATR data
00000010h: Automatic ICC clock frequency change
00000020h: Automatic baud rate according to parameters
00000040h: Automatic parameters negotiation made by the CCID
00000400h: Automatic IFSD exchange as first exchange (T=1)
00020000h: Short APDU level exchange with CCID
0x01
0x00
44
0x0F
dwMaxCCIDMessageLength (271 bytes)
0x01
0x00
0x00
48 0x00 bClassGetResponse
49 0x00 bClassEnvelope
50
0x00
wLcdLayout (0 line, 0 character per line)
0x00
52 0x00 bPINSupport (PIN verification not supported)
53 0x01 bMaxCCIDBusySlots (1 slot can be busy at the time)
Table 39 – USB Contact Smart Card Device Class Descriptor
Contact smart card interface endpoint descriptors
Contact Smart Card Interface Endpoint Descriptor (endpoint 4 Bulk Out )
Offset Value Field
0 0x07 bLength (7 bytes)
1 0x05 bDescriptorType (Endpoint)
2 0x04 bEndpointAddress (b7=0 OUT, b3-b0 = address 4)
3 0x02 bmAttributes (02h =Bulk endpoint)
4
0x40
wMaxPacketSize (64 bytes max)
0x00
6 0x00 bInterval (For full speed : Ignored)
Table 40 – USB Contact Smart Card Interface Endpoint Descriptor (Bulk Out)
Contact Smart Card Interface Endpoint Descriptor (endpoint 5 Bulk In)
Offset Value Field
0 0x07 bLength (7 bytes)
1 0x05 bDescriptorType (Endpoint)
2 0x85 bEndpointAddress (b7=1 IN, b3-b0 = address 5 )
3 0x02 bmAttributes (02h = Bulk endpoint)
4
0x40
wMaxPacketSize (64 bytes max)
0x00
6 0x00 bInterval (For full speed : Ignored)
Table 41 – USB Contact Smart Card Interface Endpoint Descriptor (Bulk In)
Contact Smart Card Interface Endpoint Descriptor (endpoint 7 Interrupt IN)
Offset Value Field
0 0x07 bLength (7 bytes)
