Reference Manual
Prox–DU & Prox–SU
www.gemalto.com
DOC118569D Public Use Page 35/145
x x 1 x 0 x x x 424 kbps card to reader allowed
x 1 x x 0 x x x 848 kbps card to reader allowed
1 x x x x x x x
Only the same bit rate for both direction is
allowed
0 x x x x x x x
Different bit rate for both direction is
allowed (do not used this setting)
Note: The list of bit rate reader to card (b2-b0) and card to reader (b6-b4) can be different.
T=CL card presence check behavior
This byte is used only for test purpose:
00h: the first dummy APDU command to check a T=CL card presence is send
(normal behavior)
01h: the first dummy APDU command to check a T=CL card presence is not used
Note: the first APDU command has the following format: 00h A4h 00h 00h 00h
Card type polling enable/disable
This byte is used to inhibit the reader to poll for a specific card type:
b0 is used to stop the polling of ISO14443-A smart cards (when set to 1)
b1 is used to stop the polling of ISO14443-B smart cards (when set to 1)
b7 is used to perform a RF reset before each REQ command (when set to 1)
b7 b6 b5 b4 b3 b2 b1 b0 Bit rate
RFU RFU RFU RFU RFU RFU X 1 Type A card polling is disabled
RFU RFU RFU RFU RFU RFU 1 X Type B card polling is disabled
0 RFU RFU RFU RFU RFU X X
A RF reset is not performed before
each REQ command
1 RFU RFU RFU RFU RFU X X
A RF reset is performed before each
REQ command
RFU bit must be set to 0.
Deactivation / Reactivation behavior
This byte is used to control the behavior when the T=CL card is deactivated and reactivated.
b7 b6 b5 b4 b3 b2 b1 b0 Behavior
RFU RFU RFU RFU RFU RFU 0 0
Deactivation with a Deselect
The card serial number is checked on
reactivation
RFU RFU RFU RFU RFU RFU 0 1
Deactivation with a Deselect
The card serial number is not
checked on reactivation
RFU RFU RFU RFU RFU RFU 1 0
Deactivation with a Deselect and a
RF reset
The card serial number is not
checked on reactivation
RFU RFU RFU RFU RFU RDU 1 1
Deactivation with a RF reset
The card serial number is not
checked on reactivation
RFU bit must be set to 0
