Gemalto Prox–DU Reference Manual

Reference Manual
Prox–DU & Prox–SU
www.gemalto.com
DOC118569D Public Use Page 119/145
1 0x05 bDescriptorType (Endpoint)
2 0x87 bEndpointAddress (b7=1 IN, b3-b0 address 7)
3 0x03 bmAttributes (Interrupt endpoint)
4
0x08
wMaxPacketSize (8 bytes max)
0x00
6 0x18 bInterval (Polling Interval =24 ms)
Table 42 – USB Contact Smart Card Interface Endpoint Descriptor (Interrupt In)
String Descriptors
LangID string descriptor
LangID String Descriptor
Offset Value Field
0 0x04 bLength (12)
1 0x03 bDescriptorType (String)
2
0x09
wLangID[0] (U.S. English = 0409h)
0x04
Table 43 – USB LangID String Descriptor
Manufacturer string descriptor
String01 (index iManufacturer of device descriptor)
Offset Value Field
0 0x10 bLength
1 0x03 bDescriptorType (String)
2
‘G,0
bString = "Gemalto"
‘e’,0
‘m’,0
‘a’,0
‘l’,0
‘t’,0
‘o’,0
Table 44 – USB Manufacturer String Descriptor
Product string descriptor
String02 (index iProduct of device descriptor)
Offset Value Field
0 0x3A bLength (58 bytes for Prox DU or 54 bytes for Prox SU )
1 0x03 bDescriptorType (String)
2
0x50,0x00
bString =
”Prox Dual USB PC Link Reader”
or
“Prox SU USB PC Link Reader”
0x72,0x00
0x6F,0x00,
0x78,0x00,
0x20,0x00,
