88
Remote IP Specify the remote (destination) IP address
Address: (e): that will be affected by this rule. Please input the
starting IP address in the left field, and input the
end IP address in the right field to define a range of
IP addresses, or just input the IP address in the left
field to define a single IP address.
Remote Port Please input the range of remote (destination)
Range (f): port number that will be affected by this rule. If you
want to apply this rule on port 80 to 90, please
input ’80-90’; if you want to apply this rule on a
single port, just input the port number, like ‘80’.
If
the remote (destination) IP address and /or port
number is universal, just leave it blank.
Traffic Type (g): Please select the traffic type of this rule,
available options are None, SMTP, HTTP, POP3,
and FTP. You can select a specific traffic type for
this rule, if you want to make this rule as a IP
address based rule (apply the limitation on all
traffics from / to the specified IP address / port
number), select ‘None’.
Protocol (h): Please select the protocol type of this rule,
available options are TCP and UDP. If you don’t
know what protocol your application uses, please
try ‘TCP’ first, and switch to ‘UDP’ if this rule
doesn’t seems to work.
After you finish with all settings, please click ‘save’ button (i), you’ll be
brought back to previous menu, and the rule you just set will appear in
current QoS table; if you did anything wrong, you’ll get an error message
when you click ‘Save’ button, please correct your input by the
instructions given by the error message.
If you want to erase all values you just entered. Click ‘Reset’
