Weld334m - User’s manual
11
2.3
Hardware configuration
Every function has been housed on a dedicated card; in addition to this, 24Vdc discrete
inputs and outputs are divided into Base and Expansion types.
The first position on the BUS, near connectors P1 and JP1, is to be compulsorily dedicated
to the card CPU.
List of available cards:
Card order
code
33037000
33035100
33036300
33038400
33035300
33036400
33036000
33035600
33037600
33035900
33038100
33038600
Card name
F370 PSM
F351 BUS
F363 DPY
F384 CPU
F353 ADC
F364 SEV
F360 IOB
F356 IOE
F376-OPC
F359-MCP
F381-ETH
F386-ETH
Card description
Order code Type
Power supply
BUS – interconnection card
4-digit Display
CPU
Analogue card
Proportional servovalve module
Basic I/O Terminal
Expansion I/O Terminal
Interbus-S optical OPC
Memory card + Printer
Ethernet card with Data Key
CAN Ethernet 10/100 Mbit with Data Key
33030102 Weld334m HC XXXXXXXX XXX
33030106 Weld334m HCM XXXXXXXX XXX
33030112 Weld334m HIC XXXXXXX XXXX
33030116 Weld334m HIM XXXXXXX XXXX
alternative
